The machine adopts advanced technology from abroad and strictly conforms to GMP requirements. Equipped with PLC controller and color touch screen and programming control. The machine can be filled with ointment, cream, jelly or sticky material. Its functions include tail folding, batch number automatic embossing (including production date). It is suitable for lead tube, aluminum alloy pipe, plastic pipe and laminated tube filling for cosmetics, pharmacy and food industry, it is your ideal equipment.


S this machine is multifunctional machine, corresponding manipulator can choose a different location and equipment, to meet different types of tail folding, sealing requirement aluminium alloy pipe, plastic pipe, plumbing, laminated tube.

Internal feeding, electronic eye marking, internal cleaning (optional), material filling, sealing (tail folding), finished product batch printing.

The pipe capacity can be moved to adjust the upper and lower height according to different pipe length. And can reverse feeding system with external, make the hose filling more convenient and tidy.

The precision tolerance of the photo sensor of the mechanical linkage device is less than 0.2mm. Reduce the range of chromatic aberrations between the tube and the electron eye.

It has integrated control of light, electricity and pneumatic, and no tube is not filled. Low pressure, automatic display (alarm); If the hose has problem the machine will automatically stop or open the safety door.

The double-layer coat is instantly heated with the internal air heater, which will not damage the outer wall and achieve a beautiful sealing effect.



Capacity 60/min(max)
Filling Volume 5-250ml
Filling Accuracy ≤±1%
Tube length 50-210mm
Tube width Φ10-50mm
Feeding method The slant is automatically fed to the warehouse.
Optional The saddle folding closure device can be realized by adjusting the folding three sides and saddle folding.
Optional Interlayer material drum insulation device.
Optional Drum internal mixing device.
Optional Automatic control feeding device (pump)
Optional Automatic control feeding device (pump)
Optional Finished tube output transmission device.
Application Metal tubes
